| Чипсет |
Intel NM70 |
| Процесор |
Built in with an Intel Dual-core Celeron 1007U processor (1.5 GHz), 2 MB L3 cache |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory , Dual channel memory architecture, Support for DDR3 1333/1066 MHz memory modules |
| Портове |
Up to 8 USB 2.0/1.1 ports, PS/2 keyboard port, PS/2 mouse port, D-Sub port, serial port, HDMI port, 4 x USB 2.0/1.1 ports, eSATA 3Gb/s connector, 2 x RJ-45 ports, 3 x audio jacks |
| Слотове |
PCI slot |
| Дисков интерфейс |
SATA 6Gb/s connector (SATA3 0) supporting up to 1 SATA 6Gb/s device, 2 x SATA 3Gb/s connectors (SATA2 1~2) supporting up to 2 SATA 3Gb/s devices, eSATA 3Gb/s connector on the back panel supporting up to 1 SATA 3Gb/s device, IDE connector supporting ATA-13 |
| Видео |
D-Sub port, HDMI port, supporting a maximum resolution of 1920x1200 * Support for HDMI 1.4 version., Maximum shared memory of 1 GB |
| Аудио |
Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN |
2 x Realtek GbE LAN chips (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
Mini-ITX |
| Други |
Dimensions 17.0cm x 17.0cm |
| Гаранционен срок |
36 месеца |
