| Чипсет |
AMD A45 FCH |
| Съвместими процесори |
Built in with an AMD E-240 Single-Core processor; Built in with an AMD Radeon HD 6310 (DirectX 11) graphics core |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory; Single channel memory architecture; Support for DDR3 1333 (O.C.)/1066 MHz memory modules |
| Портове |
1 x PS/2 keyboard port; 1 x PS/2 mouse port; 1 x parallel port; 1 x serial port; 1 x D-Sub port; 1 x HDMI port; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks (Line In/Line Out/Microphone) |
| Слотове |
1 x PCI slot |
| Дисков интерфейс |
4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices |
| Видео |
Integrated in the APU: 1 x D-Sub port; 1 x HDMI port, supporting a maximum resolution of 1920x1200 |
| Аудио |
Realtek ALC887 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash; Use of licensed AWARD BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
| Форм фактор |
Mini-ITX |
| Други |
Dimensions 17.0cm x 17.0cm |
| Гаранционен срок |
36 месеца |
