| Чипсет |
AMD A55 |
| Процесор |
AMD A series processors, AMD Athlonseries processors |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR3 2400(OC)/1866/1600/1333/1066 MHz memory modules, Support for AMD Memory Profile (AMP)/ Extreme Memory Profile (XMP) memory modules |
| Multi-GPU Support |
Support for AMD Dual Graphics technology |
| Портове |
Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
| Слотове |
PCI Express x16 slot, running at x16,PCI Express x1 slot, PCI slot |
| Дисков интерфейс |
4 x SATA 3Gb/s connectors, Support for RAID 0, RAID 1, RAID 10, and JBOD |
| Видео |
1 x D-Sub port, supporting a maximum resolution of 1920x1200, Maximum shared memory of 2 GB |
| Аудио |
Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
32 Mbit flash, Use of licensed AMI EFI BIOS,PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
| Форм фактор |
Micro ATX |
| Други |
Dimensions 22.5cm x 17.4cm |
| Гаранционен срок |
36 месеца |
