| Чипсет |
Intel Z87 Express Chipset |
| Процесор |
Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package; L3 cache varies with CPU |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory; Dual channel memory architecture |
| Портове |
1 x PS/2 keyboard/mouse port; 2 x HDMI ports; 1 x DisplayPort; 1 x coaxial S/PDIF Out connector; 1 x optical S/PDIF Out connector; 6 x USB 3.0/2.0 ports; 2 x USB 2.0/1.1 ports; 2 x RJ-45 ports |
| Слотове |
2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2); 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2); 3 x PCI Express x1 slots; (All PCI Express x1 slots conform to PCI Express 2.0 standard.) |
| Дисков интерфейс |
Chipset:6 x SATA 6Gb/s connectors (SATA3 0~5) supporting up to 6 SATA 6Gb/s devices; Support for RAID 0, RAID 1, RAID 5, and RAID 10; Marvell 88SE9230 chip:4 x SATA 6Gb/s connectors (GSATA3 6~9) supporting up to 4 SATA 6Gb/s devices |
| Видео |
Integrated Graphics Processor:2 x HDMI ports, supporting a maximum resolution of 4096x2160; 1 x DisplayPort, supporting a maximum resolution of 3840x2160; Maximum shared memory of 1 GB |
| Аудио |
Creative Sound Core 3D chip; Support for Sound Blaster Recon3Di; High Definition Audio; 2/5.1-channel; Support for S/PDIF Out |
| LAN |
1 x Qualcomm Atheros Killer E2201 chip (10/100/1000 Mbit) (LAN1); 1 x Intel GbE LAN phy (10/100/1000 Mbit) (LAN2) |
| BIOS |
2 x 128 Mbit flash; Use of licensed AMI EFI BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
E-ATX |
| Други |
Wireless Communication module Wi-Fi 802.11 a/b/g/n, supporting 2.4/5 GHz Dual-BandBluetooth 4.0, 3.0+HS, 2.1+EDR; Dimensions 30.5cm x 26.4cm |
| Гаранционен срок |
36 месеца |
