| Чипсет |
Intel H61 Express Chipset |
| Процесор |
Support for Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1155 package, 2.L3 cache varies with CPU |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory, Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memo |
| Портове |
Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers), Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header), Support for USB Battery Charge 1.2 |
| Слотове |
PCI Express x16 slot, running at x16, PCI Express x1 slot |
| Дисков интерфейс |
4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices |
| Видео |
D-Sub port, DVI-D port, supporting a maximum resolution of 1920x1200 |
| Аудио |
Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
Micro ATX Form Factor; 22.6cm x 17.4cm |
| Гаранционен срок |
36 месеца |
