| Чипсет |
Intel H61 Express Chipset |
| Процесор |
Support for an Intel Core i7 series processor |
| Съвместими процесори |
Intel Core i5 series processor; Intel Core i3 series processor; Intel Pentium processors; Intel Celeron processors in the LGA1155 package L3 cache varies with CPU |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory; Dual channel memory architecture; Support for DDR3 1333/1066/800 MHz memory modules; Support for non-ECC memory modules |
| Портове |
1 x optical S/PDIF Out connector; 1 x coaxial S/PDIF Out connector; 1 x D-Sub port;31 x DVI-D port; 1 x HDMI port; 4 x USB 2.0/1.1 ports; 2 x USB 3.0/2.0 ports; 1 x eSATA 3Gb/s connector; 1 x RJ-45 port; 3 x audio jacks (Line In/Line Out/Microphone) |
| Слотове |
1 x PCI Express x16 slot, running at x16 (The PCIEX16 slot conforms to PCI Express 2.0 standard.) |
| Дисков интерфейс |
2 x SATA 3Gb/s connectors (SATA2_0, SATA2_1) supporting up to 2 SATA 3Gb/s devices; 1 x eSATA 3Gb/s connector on the back panel supporting up to 1 SATA 3Gb/s device |
| Видео |
1 x D-Sub port; 1 x DVI-D port, supporting a maximum resolution of 1920x1200; 1 x HDMI port, supporting a maximum resolution of 1920x1200 |
| Аудио |
Realtek ALC889 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| LAN |
1 x Realtek RTL8111E chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash; Use of licensed AWARD BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
| Форм фактор |
Mini-ITX |
| Други |
Dimensions 17.0cm x 17.0cm |
| Гаранционен срок |
36 месеца |
