| Чипсет |
Intel H87 Express Chipset |
| Съвместими процесори |
Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package; L3 cache varies with CPUSupport for Intel Core i7 processors/Intel Core i5 processors/Intel Co |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory |
| Multi-GPU Support |
Support for AMD CrossFire technology |
| Портове |
1 x PS/2 keyboard/mouse port; 1 x D-Sub port; 1 x DVI-D port; 1 x HDMI port; 4 x USB 3.0/2.0 ports; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 1 x optical S/PDIF Out connector; 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out |
| Слотове |
1 x PCI Express x16 slot, running at x16 (PCIEX16) (The PCIEX16 slot conforms to PCI Express 3.0 standard.) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot |
| Дисков интерфейс |
6 x SATA 6Gb/s connectors (SATA3 0~SATA3 5) supporting up to 6 SATA 6Gb/s devices; Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Аудио |
Realtek ALC892 codec; High Definition Audio; ; /4/5.1/7.1-channel; Support for S/PDIF In; Support for S/PDIF Out |
| LAN |
Intel GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 64 Mbit flash; Use of licensed AMI EFI BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
ATX |
| Други |
30.5cm x 22.5cm |
| Гаранционен срок |
36 месеца |
