Характеристики
Характеристики
| Процесор | Built in with an Intel Qual-Core Celeron N3150 SoC (1.6 GHz), 2 MB Cache |
|---|---|
| Памет | 2 x DDR3 DIMM sockets supporting up to 8 GB of system memory, Dual channel memory architecture, Support for DDR3/DDR3L 1600/1333 MHz memory modules, Support for non-ECC memory modules |
| Портове | 1 x PS/2 keyboard/mouse port, 1 x D-Sub port, 1 x HDMI port, 1 x serial port, 1 x parallel port, 2 x USB3.0/2.0 port, 2 x USB 2.0/1.1 port, 1 x RJ-45 port, 3 x audio jacks (Line In, Line Out, Mic In) |
| Слотове | 1 x PCI Express x4 slot, running at x1 (PCIEX1_2), 1 x PCI Express x1 slot, running at x1 (PCIEX1_1), 1 x PCI slot |
| Конектори | 1 x 24-pin ATX main power connector; 1 x 4-pin ATX 12V power connector; 2 x SATA 6Gb/s connectors; 1 x CPU fan header; 1 x system fan header; 1 x front panel header; 1 x front panel audio header; 1 x USB 3.0/2.0 header; 2 x USB 2.0/1.1 header; 1 x Trusted Platform Module (TPM) header; 1 x serial port header; 1 x Clear CMOS jumper; |
| Дисков интерфейс | Integrated in the SoC: 2 x SATA 6Gb/s connectors |
| Видео | Integrated in the SoC: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x HDMI port, supporting a maximum resolution of 3840x2160@30 Hz, Maximum shared memory of 512 MB |
| Аудио | Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN | Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS | 1 x 64 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор | Micro ATX Form Factor; 22.6cm x 18.0cm |
| Други | Support for Xpress Install, Support for @BIOS, Support for APP Center |
| Гаранционен срок | 36 месеца |
