Характеристики
Характеристики
| Процесор | Built in with an Intel Quad-Core Celeron N3150 SoC (1.6 GHz) 2 MB Cache |
|---|---|
| Памет | 2 x DDR3 SO-DIMM sockets supporting up to 8 GB of system memory, Dual channel memory architecture, Support for DDR3/DDR3L 1600/1333 MHz memory modules, Support for non-ECC memory modules |
| Портове | 1 x PS/2 mouse port, 1 x PS/2 Keyboard port 2 x serial ports, 1 x D-Sub port, 1 x DVI-D port, 2 x USB 3.0/2.0 ports, 2 x USB 2.0/1.1 ports, 2 x RJ-45 ports, 3 x audio jacks (Line In, Line Out, Mic In) |
| Слотове | 1 x PCI slot, 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) |
| Конектори | 1 x 24-pin ATX main power connector; 1 x 4-pin ATX 12V power connector; 4 x SATA 6Gb/s connectors; 1 x CPU fan header; 1 x system fan header; 1 x front panel header; 1 x front panel audio header; 1 x USB 3.0/2.0 header; 2 x USB 2.0/1.1 headers; 1 x parallel port header; 1 x Clear CMOS jumper; 1 x chassis intrusion header |
| Дисков интерфейс | SoC: 2 x SATA 6Gb/s connectors (SATA 3 0/1), ASMedia ASM1061 chip: 2 x SATA 6Gb/s connectors (SATA 3 2/3) |
| Видео | Integrated in the SoC: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz |
| Аудио | Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel |
| LAN | 2 x Realtek GbE LAN chips (10/100/1000 Mbit) |
| BIOS | 2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор | Mini-ITX Form Factor; 17.0cm x 17.0cm |
| Гаранционен срок | 36 месеца |
