Характеристики
Характеристики
| Чипсет | Intel C232 Chipset |
|---|---|
| Съвместими процесори | Support for Intel Xeon E3-1200 v5 processors/Intel Core processors/ Intel Pentium processors/Intel Celeron processors in the LGA1151 package, L3 cache varies with CPU |
| Памет | 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR4 2133 MHz memory modules, Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules |
| Multi-GPU Support | Support for 2-Way AMD CrossFire technology |
| Портове | 1 x PS/2 keyboard port, 1 x PS/2 mouse port, 2 x USB 2.0/1.1 ports, 4 x USB 3.0/2.0 ports, 1 x RJ-45 port, 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) |
| Слотове | 1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.), 2 x PCI slots |
| Конектори | 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x M.2 Socket 3 connector; 1 x SATA Express connector; 6 x SATA 6Gb/s connectors; 1 x CPU fan header; 3 x system fan headers; 1 x front panel header; 1 x front panel audio header; 1 x S/PDIF Out header; 1 x USB 3.0/2.0 header; 2 x USB 2.0/1.1 headers; 1 x Trusted Platform Module (TPM) header; 1 x Thunderbolt add-in card connector; 1 x serial port header; 1 x parallel port header; 1 x Clear CMOS jumper |
| Дисков интерфейс | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2/x1 SSD support), 1 x SATA Express connector, 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Аудио | Realtek ALC892 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out |
| LAN | Intel GbE LAN chip (10/100/1000 Mbit) |
| BIOS | 2 x 64 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор | ATX Form Factor; 30.5cm x 20.0cm |
| Гаранционен срок | 36 месеца |
