Характеристики
Характеристики
| Чипсет | Intel Z170 Express Chipset |
|---|---|
| Съвместими процесори | Support for Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/ Intel Celeron processors in the LGA1151 package, L3 cache varies with CPU |
| Памет | 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR4 3466(O.C.) /3400(O.C.) /3333(O.C.) /3300(O.C.) /3200(O.C.) /3000(O.C.) /2800(O.C.) /2666(O.C.) /2400(O.C.) /2133 MHz memory modules, Support |
| Multi-GPU Support | Support for 3-Way/2-Way AMD CrossFire and 2-Way NVIDIA SLI Technology |
| Портове | 1 x PS/2 keyboard/mouse port, 1 x D-Sub port, 1 x DVI-D port, 1 x HDMI port, 1 x USB Type-C port, with USB 3.1 support, 1 x USB 3.1 Type-A port (red), 3 x USB 3.0/2.0 ports, 2 x USB 2.0/1.1 ports, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 5 x audi |
| Слотове | 1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x8 (PCIEX8), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 3 x PCI Express x1 slots |
| Конектори | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x M.2 Socket 3 connectors 3 x SATA Express connectors 6 x SATA 6Gb/s connectors 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 3 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB 3.0/2.0 headers 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header 1 x Thunderbolt™ add-in card connector 1 x serial port header 1 x Clear CMOS jumper 1 x audio gain control switch |
| Дисков интерфейс | 2 x M.2 Socket 3 connectors (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x4/x2/x1 SSD support), 3 x SATA Express connectors, 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Видео | Integrated Graphics Processor-Intel HD Graphics support 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 |
| Аудио | Realtek ALC1150 codec, TI Burr Brown OPA2134 operational amplifier, Support for Sound Blaster X-Fi MB3, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out |
| LAN | Killer E2201 LAN chip (10/100/1000 Mbit) |
| BIOS | 2 x 64 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор | ATX Form Factor; 30.5cm x 23.5cm |
| Други | Support for APP Center 3D OSD, @BIOS, Ambient LED, AutoGreen, Cloud Station, EasyTune, Easy RAID, Fast Boot, Smart TimeLock, Smart Keyboard, Smart Backup, System Information Viewer, USB Blocker; Support for Q-Flash; Support for Smart Switch; Support for X |
| Гаранционен срок | 36 месеца |
