Характеристики
Характеристики
| Чипсет | Intel Z170 Express Chipset |
|---|---|
| Съвместими процесори | Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package, L3 cache varies with CPU |
| Памет | 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR4 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) |
| Multi-GPU Support | Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies, Support for AMD Quad-GPU CrossFireX™ and 2-Way AMD CrossFire™ technologies |
| Портове | 1 x PS/2 keyboard/mouse port, 1 x USB Type-C™ port, with USB 3.1 support, 1 x USB 3.1 Type-A port (red), 1 x Mini-DisplayPort In port, 1 x Mini-DisplayPort, 1 x HDMI port, 4 x USB 3.0/2.0 ports, 2 x USB 2.0/1.1 ports, 1 x RJ-45 port, 1 x optical S/PDIF Ou |
| Слотове | 1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x8 (PCIEX8), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 3 x PCI Express x1 slots |
| Конектори | 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x U.2 connector; 1 x M.2 Socket 3 connector; 2 x SATA Express connectors; 6 x SATA 6Gb/s connectors; 1 x CPU fan header; 1 x water cooling fan/pump header (CPU_OPT_PUMP); 2 x system fan headers; 1 x system fan/water cooling pump header (SYS_FAN2_PUMP); 1 x front panel header; 1 x front panel audio header; 1 x USB 3.0/2.0 header; 2 x USB 2.0/1.1 headers; 1 x S/PDIF Out header; 1 x Trusted Platform Module (TPM) header; 1 x Thunderbolt add-in card connector; 1 x Clear CMOS jumper |
| Дисков интерфейс | Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support), 1 x U.2 connector, 2 x SATA Express connectors, 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Видео | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz, 1 x Mini-DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz |
| Аудио | Realtek ALC892 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out |
| LAN | Intel GbE LAN chip (10/100/1000 Mbit) |
| BIOS | 2 x 128 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор | ATX Form Factor; 30.5cm x 24.4cm |
| Гаранционен срок | 36 месеца |
