| Чипсет |
Intel Z87 Express Chipset |
| Процесор |
Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory, Dual channel memory architecture, Support for DDR3 2933(O.C.)/1600/1333 MHz memory modules, Support for non-ECC memory modules, Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
PS/2 keyboard/mouse port, D-Sub port, DVI-D port, HDMI port, 4 x USB 3.0/2.0 ports, 2 x USB 2.0/1.1 ports, RJ-45 port, 3 x audio jacks |
| Слотове |
PCI Express x16 slot, running at x16 , 2 x PCI Express x1 slots, PCI slot |
| Дисков интерфейс |
6 x SATA 6Gb/s connectors supporting up to 6 SATA 6Gb/s devices, Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Видео |
D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz, HDMI port, supporting a maximum resolution of 4096x2160@24 Hz, Maximum shared memory of 1 GB |
| Аудио |
Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 64 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS™, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
Micro ATX |
| Други |
Dimensions 24.4cm x 17.4cm |
| Гаранционен срок |
36 месеца |
