| Чипсет |
Intel Z87 Express Chipset |
| Съвместими процесори |
Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package, L3 cache varies with CPU |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory, 1600 / 1333 MHz memory modules |
| Портове |
24-pin ATX main power connector, 8-pin ATX 12V power connector, 6 x SATA 6Gb/s connectors, CPU fan header, 3 x system fan headers, front panel header, front panel audio header, S/PDIF In header, S/PDIF Out header, USB 3.0/2.0 header |
| Слотове |
PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot., PCI Express x16 slot, running at x8 (PCIEX8) (The PCIEX16 and PCIEX8 slots |
| Дисков интерфейс |
6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Видео |
D-Sub port, supporting a maximum resolution of 1920x1200, DVI-D port, supporting a maximum resolution of 1920x1200 * The DVI-D port does not support D-Sub connection by adapter., HDMI port, supporting a maximum resolution of 4096 x 2160 @ 24 Hz / 2560 x 1 |
| Аудио |
Realtek ALC892 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF In/Out |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 64 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
ATX Form Factor; 30.5cm x 22.5cm |
| Други |
Support for Q-Flash, Support for Xpress Install, Support for ON/OFF Charge, Support for APP Center |
| Гаранционен срок |
36 месеца |
