| Чипсет |
Intel Z87 Express Chipset |
| Процесор |
Support for Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory; ; Dual channel memory architecture; Support for DDR3 1600/1333 MHz memory modules; Support for non-ECC memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
1 x PS/2 keyboard/mouse port; 1 x D-Sub port; 1 x DVI-D port; 1 x HDMI port; 1 x DisplayPort; 1 x optical S/PDIF Out connector; 6 x USB 3.0/2.0 ports; 2 x eSATA 6Gb/s connectors; 1 x RJ-45 port |
| Слотове |
1 x PCI Express x16 slot, running at x16 (PCIEX16); 1 x PCI Express x16 slot, running at x8 (PCIEX8) (The PCIEX16 and PCIEX8 slots conform to PCI Express 3.0 standard.); 1 x PCI Express x16 slot, running at x4 (PCIEX4); 3 x PCI Express x1 slots |
| Дисков интерфейс |
Chipset:6 x SATA 6Gb/s connectors (SATA3 0~5) supporting up to 6 SATA 6Gb/s devices; Support for RAID 0, RAID 1, RAID 5, and RAID 10; Marvell 88SE9172 chip:; 2 x SATA 6Gb/s connectors (GSATA3 6/7) or 2 eSATA 6Gb/s connectors on the back panel |
| Видео |
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz; 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz; 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz |
| Аудио |
Realtek ALC898 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF In/Out |
| LAN |
Intel GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 128 Mbit flash; Use of licensed AMI EFI BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.6 |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5cm x 24.4cm |
| Гаранционен срок |
36 месеца |
