| Чипсет |
Intel Z87 Express |
| Процесор |
CPU Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1150 package, L3 cache varies with CPU |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory, Dual channel memory architecture, Support for DDR3 3000(O.C.) / 2933(O.C.) / 2800(O.C.) / 2666(O.C.) / 2600(O.C.) / 2500(O.C.) / 2400(O.C.) / 2200(O.C.) / 2133(O.C.) / 2000(O.C.) |
| Multi-GPU Support |
Support for 2-Way AMD CrossFire/2-Way NVIDIA SLI technology (PCIEX16 and PCIEX8) |
| Портове |
Up to 2 USB 3.0/2.0 ports, Up to 6 USB 2.0/1.1 ports, Up to 8 USB 3.0/2.0 ports, PS/2 keyboard/mouse port, D-Sub port, DVI-D port, HDMI port, DisplayPort, optical S/PDIF Out connector, 6 x USB 3.0/2.0 ports, 2 x eSATA 6Gb/s connectors, RJ-45 port |
| Слотове |
PCI Express x16 slot, running at x16 (PCIEX16) 1 x PCI Express x16 slot, running at x8 (PCIEX8) (The PCIEX16 and PCIEX8 slots conform to PCI Express 3.0 standard.) 1 x PCI Express x16 slot, running at x4 (PCIEX4) 3 x PCI Express x1 slots |
| Дисков интерфейс |
6 x SATA 6Gb/s connectors (SATA3 0~5) supporting up to 6 SATA 6Gb/s devices, Support for RAID 0, RAID 1, RAID 5, and RAID 10, 2 x SATA 6Gb/s connectors (GSATA3 6/7) or 2 eSATA 6Gb/s connectors on the back panel, supporting up to 2 SATA 6Gb/s devices |
| Видео |
D-Sub port, supporting a maximum resolution of 1920x1200, DVI-D port, supporting a maximum resolution of 1920x1200, HDMI port, supporting a maximum resolution of 4096x2160 , DisplayPort, supporting a maximum resolution of 3840x2160 |
| Аудио |
Realtek ALC898 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF In/Out |
| LAN |
Intel GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 128 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5cm x 24.4cm |
| Гаранционен срок |
36 месеца |
