| Чипсет |
Intel H61 Express Chipset |
| Процесор |
Support for Intel Core i7 processors |
| Съвместими процесори |
Intel Core i5 processors; Intel Core i3 processors; Intel Pentium processors; Intel Celeron processors in the LGA1155 package |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory ; Dual channel memory architecture; Support for DDR3 1333/1066/800 MHz memory modules; Support for non-ECC memory modules |
| Портове |
1 x PS/2 keyboard port; 1 x PS/2 mouse port;1 x serial port; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks (Line In/Line Out/Microphone) |
| Слотове |
1 x PCI Express x16 slot, running at x16; 2 x PCI Express x1 slots; (All PCI Express slots conform to PCI Express 2.0 standard.); 3 x PCI slots |
| Дисков интерфейс |
4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices |
| Аудио |
VIA VT1708 codec ; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| LAN |
1 x Atheros AR8151 chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash; Use of licensed AWARD BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5cm x 19.0cm |
| Гаранционен срок |
36 месеца |
