| Чипсет |
Intel X79 Express Chipset |
| Съвместими процесори |
Support for Intel Core i7 processors in the LGA2011 package |
| Памет |
8 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory; 4 channel memory architecture; Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules; Support for non-ECC memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
1 x PS/2 keyboard/mouse port; 1 x optical S/PDIF Out connector; 1 x coaxial S/PDIF Out connector; 8 x USB 2.0/1.1 ports; 2 x USB 3.0/2.0 ports; x eSATA 6Gb/s connectors; 1 x RJ-45 port; 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side |
| Слотове |
2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2); 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)(All PCI Express x16 slots conform to PCI Express 3.0 standard.) |
| Дисков интерфейс |
Chipset: 2 x SATA 6Gb/s connectors (SATA3 0/1) supporting up to 2 SATA 6Gb/s devices; 4 x SATA 3Gb/s connectors (SATA2 2~5) supporting up to 4 SATA 3Gb/s devices; Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Аудио |
Realtek ALC892 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| LAN |
Intel GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 64 Mbit flash; Use of licensed AMI EFI BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5cm x 24.4cm |
| Гаранционен срок |
36 месеца |
