| Чипсет |
Intel Z77 Express Chipset |
| Съвместими процесори |
Support for Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1155 package |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory; Dual channel memory architecture; Support for DDR3 2400(OC)/1600/1333/1066 MHz memory modules; Support for non-ECC memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
1 x PS/2 keyboard/mouse port; 1 x D-Sub port; 1 x DVI-D port; 1 x HDMI port; 4 x USB 3.0/2.0 ports; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 1 x optical S/PDIF Out connector; 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out |
| Слотове |
1 x PCI Express x16 slot, running at x16 (PCIEX16) (The PCIEX16 slot conforms to PCI Express 3.0 standard.); 1 x PCI Express x16 slot, running at x4 (PCIEX4); 3 x PCI Express x1 slots (PCIEX4 and PCIEX1 slots conform to PCI Express 2.0 standard.) |
| Дисков интерфейс |
2 x SATA 6Gb/s connectors (SATA3 0/SATA3 1) supporting up to 2 SATA 6Gb/s devices, 4 x SATA 3Gb/s connectors (SATA2 2~SATA2 5) supporting up to 4 SATA 3Gb/s devices, 1 x mSATA connector, Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Видео |
1 x D-Sub port, 1 x DVI-D port supporting a maximum resolution of 1920x1200, 1 x HDMI port supporting a maximum resolution of 1920x1200 |
| Аудио |
VIA VT2021 codec; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out |
| LAN |
Atheros GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5cm x 24.4cm |
| Гаранционен срок |
36 месеца |
