| Чипсет |
Intel NM10 Express Chipset |
| Процесор |
Passively-cooled, soldered-down Dual-Core Intel Atom Processor D2500 (1M Cache, 1.86 GHz) with integrated graphics and integrated memory controller |
| Памет |
2 x 204-pinDDR3 SDRAM Small Outline Dual Inline Memory Module (SO DIMM) sockets; Support for DDR3 1066 MHz, DDR3 1333 MHz, and DDR3 1600 MHz SO DIMMs Note: DDR3 1333 MHz and DDR3 1600 MHz memory will run at 1066 MHz |
| Портове |
Serial port; Parallel port; VGA port; PS/2 keyboard/mouse port; 4 x USB ports; LAN port; Line in; Line out; Mic in |
| Слотове |
One PCI Conventional Bus Connector |
| Видео |
Intel Graphics Media Accelerator 3600 |
| Аудио |
Intel High Definition Audio (Intel HD Audio) subsystem in the following configuration:Four (2+2) channel Intel HD Audio; Front panel mic/headphone header (2x5) |
| LAN |
Integrated Intel 10/100/1000 network connection |
| BIOS |
8 Mb Flash EEPROM |
| Форм фактор |
Mini-ITX |
| Други |
Dimensions 170 millimeters x 170 millimeters |
| Гаранционен срок |
36 месеца |
