| Чипсет |
Intel C222 Express PCH |
| Процесор |
Intel Xeon processor E34-1200 v3 and 4th Gen Core i3, Pentium, Celeron processors |
| Памет |
Memory Capacity: 4x 240-pin DDR3 DIMM sockets; Supports up to 32 GB DDR3 ECC Un-Buffered memory (UDIMM); Memory Type: 1600MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs; DIMM Sizes: 8GB, 4GB, 2GB, 1GB; Memory Voltage: 1.5V, 1.35V; Error Detection |
| Портове |
Serial ATA: 2x SATA3 (6Gbps) ports; 4x SATA2 (3Gbps) ports; SAS: 8x SAS2 (6Gbps) ports; LAN: 2x RJ45 Gigabit Ethernet LAN ports; 1x RJ45 Dedicated IPMI LAN port ; USB: 2x USB 3.0 ports (1 via header, 1 Type-A); 6x USB 2.0 ports (4 rear, 2 via header); VGA |
| Слотове |
PCI-Express 1x PCI-E 3.0 x8 (in x16) slot; 1x PCI-E 2.0 x4 (in x8) slot |
| Видео |
BMC integrated Aspeed AST2400 |
| LAN |
Intel i210AT dual port GbE Controllers; Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output; 1x Realtek RTL8201N PHY (dedicated IPMI) |
| BIOS |
BIOS Type 128Mb SPI Flash EEPROM with AMI BIOS; BIOS Features DMI (SMBIOS) 2.7; ACPI 5.0; USB Keyboard support |
| Форм фактор |
uATX |
| Други |
Dimensions 9.6" x 9.6", (24.4cm x 24.4 cm) |
| Гаранционен срок |
24 месеца |
