| Чипсет |
Intel C602 chipset |
| Съвместими процесори |
Intel Xeon processor E5-2600/1600 and E5-2600/1600 v2 family (up to 12 cores and up to 150W) |
| Памет |
8x 240-pin DDR3 DIMM sockets; Up to 512GB DDR3 ECC LRDIMM; Up to 256GB DDR3 ECC RDIMM; Up to 64GB DDR3 ECC/non-ECC UDIMM |
| Портове |
SATA: 2x SATA 3.0 ports (6Gb/s); 4x SATA 2.0 ports (3Gb/s); SCU: 4x SATA 2.0 ports (3Gb/s) via SCU; LAN: 2x RJ45 Gigabit Ethernet LAN ports; USB: 4x USB 3.0 ports (5Gbps); 14x USB 2.0 ports total (8x rear + 6x via header); Audio: Line-in / Line-out / Micr |
| Слотове |
PCI-E / PCI; 2x PCI-E 3.0 x16 slots; 1x PCI-E 3.0 x4 (in x8) slot; 1x PCI-E 2.0 x4 (in x8) slot; 1x PCI-32 slot |
| Аудио |
RealTek ALC889 7.1 High Definition Audio with S/PDIF header |
| LAN |
Intel 82579LM and 82574L, 2x Gigabit LAN ports |
| BIOS |
BIOS Type: 64Mb SPI Flash EEPROM with AMI BIOS; BIOS Features: Plug and Play (PnP); APM 1.2; DMI 2.3; PCI 2.3; ACPI 1.0 / 2.0 / 3.0 / 4.0; USB Keyboard support; Hardware BIOS Virus protection; SMBIOS 2.7.1; UEFI 2.3.1; RTC (Real Time Clock) Wakeup |
| Форм фактор |
ATX |
| Гаранционен срок |
24 месеца |
