| Вход |
Low voltage transfer: 175 VAC - %80-100, 150VAC - %70-80, 130 VAC - %60-70, 110 VAC - %0-60, Low voltage correction: 195 VAC - %80-100, 170VAC - %70-80, 150 VAC - %60-70, 130 VAC - %0-60, High voltage transfer: 280 VAC ± %5, High voltage correction: 270 V |
| Изход |
Output voltage: 208/220/230/240 VAC, Voltage regulation battery mode: ± %1, Frequency range battery mode: 50 ± 0.25 Hz - 60 ± 0.3 Hz, Over load line mode: %105-110 Over load alarm, %110-130 30s to By-pass, %130-150 1.5s By-pass |
| Честота |
Output 47-53 Hz or 57-63 Hz, Input 40 - 70 Hz |
| Портове за управление |
RS 232, USB, Ethernet (Optional) |
| Батерия |
Battery type: Yuasa 12V / 10Ah, Charging time: Up to %90 capacity 5 Hour, Charge voltage: 109.4 VDC ± %1, Charge current: 1.0 A (Max.) |
| Дисплей |
LCD Panel |
| Мощност |
Capacity 6 kVA / 4200 W |
| Размер |
(DxHxW) (mm)445x340x190 |
| Тегло (нето) |
35.3 Kg |
| Гаранционен срок |
24 месеца |
