| Вход |
Low voltage transfer: %50 load 110 VAC ± %3 %100 load 176 VAC ± %3, Low voltage correction: %50 load 120 VAC ± %3 %100 load 186 VAC ± %3, High voltage transfer: 300 VAC ± %3, High voltage correction: 290 VAC ± %3, Phase: 3 Phase + Notr + PE, Power fac |
| Изход |
Output voltage: 208/220/230/240 VAC (1 Phase + Notr + PE), Voltage regulation battery mode: ± %1, Frequency range battery mode: 50 ± 0.1 Hz - 60 ± 0.1 Hz, Over load line mode: %100-110 >10 min. to By-pass, %110-130 >1 min. to By-pass, >%130 Break outpu |
| Честота |
Output 46-54 Hz or 56-64 Hz, Input 46 - 54 Hz or 56 - 64 Hz |
| Портове за управление |
RS 232, USB, Ethernet (Optional) |
| Батерия |
Battery type: 12V / 9Ah, Charging time: Up to %90 capacity 9 Hour, Charge voltage: 273.0 VDC ± %1, Charge current: 1.0 A ± %10 Max.2.0 A ± %10, External battery support: Yes, External battery charge current: 4.0 A ± %10 Max.6.0 A ± %10 |
| Дисплей |
LCD Panel |
| Мощност |
Capacity 10 kVA / 8 kW |
| Размер |
(DxHxW) (mm)592x250x576 |
| Тегло (нето) |
83.0 Kg |
| Гаранционен срок |
24 месеца |
